STRPACK supplies a complete range of equipment to fill corrosive products to meet nearly any application. Made from HDPE (high density polyethylene, these filling machines, conveyors and turntables are designed to handle the punishment of a highly corrosive environment where standard metal components would normally dissolve.
STRPACK filling systems use volumetric filling methods, which are extremely accurate and versatile. The fillers are designed to fill from a fraction of an ounce up to five gallons and are capable of handling viscosities ranging from thin and foamy to very thick liquids. STRPACK’s modular design can allow the design of the filler machines to have multiple tanks and fill head assemblies to isolate non-compatible products within a common frame. All STRPACK fillers are built to provide the best combination of maximum versatility, easy setup and changeover, and minimal down-time for maintenance and cleaning. STRPACK also manufactures this type of bottling equipment for table-top applications.
The Conveyors and Turntables are a natural development from the Filler and have proved to be valuable assets to those who package corrosive products.
ACIDS & CORROSIVE BOTTLING EQUIPMENT APPLICATIONS:
Water-thin and foaming corrosive liquids
Medium viscosity corrosive liquids
Acids such as hydrochloric acid
Bases such as sodium hypochlorite
Pool chemicals
Cleaning products
STANDARD FILLING MACHINES SPECIFICATIONS:
Fillers
HDPE (high density polyethylene filling systems frame construction
HDPE reservoir with poly float system
Kynar or Teflon fill valves
Braided PVC tubing and polypropylene fittings
Touch-screen operator interface
Tabletop, semi-automatic and fully automatic filling machines available
Optional enclosures for ventilation and safety can be fabricated out of HDPE
Conveyors
HDPE and PVC construction, stainless steel hardware
Corrosive resistant HDPE belting
Variable speed motor
HDPE rail system with tool-less adjustments
Adjustable height
Turntables
HDPE construction
Variable speed motor
Clockwise or counter clockwise rotation
HDPE rail system with tool-less adjustments
Adjustable height
STRPACK BOTTLING EQUIPMENT ADVANTAGES
Our bottling equipment features robust construction from HDPE, UHMW, and PVC construction which holds up to corrosive environments.
Easy cleaning STRPACK’s filling machines are design and constructed to allow for a “quick flush” which maximizes their cleaning efficiency.
Flexibility, versatility and simplicity are key components of each of the filling systems we design. This allows many products and containers can be run on one machine with tool-less changeover. By choosing the right filling methods, a large variety of products can be filled.
All of our bottling equipment is customized for your specific application. The tank capacity, number of fill heads, contact parts, and frame dimensions are all customizable for your particular needs. STRPACK filling machines are simple, easy to use, and feature quick setup & change over. Operators can store fill times as “recipes” for quick setup.
From Entry-level table top systems to fully automated end to end corrosive filling systems, our experts oversee every step of design, manufacturing and installation of your bottling equipment.
